Thermal Overload Relay For Electric Motors, 12 To 18A, 690V, 50 To 60Hz, Phase Break Protection, Auto Or Manual Reset, Temperature Compensation, Heavy Duty Motor Protector For Industrial Control Panels

Heavy-Duty Thermal Overload Relay for 12-16A Motors
✔️ Rated 12-16A, 690V insulation, 50-60Hz, auto/manual reset

This thermal overload relay protects electric motors in industrial control panels. It is designed for 50-60 Hz circuits and uses up to 690V insulation to guard against phase loss and overheating.

✅ RATED CURRENT: 12-16A; SIZE: 3.1 in x 3.8 in x 2.4 in
✅ RATED INSULATION VOLTAGE: 690V
✅ OPERATION: 50-60 Hz, phase break protection
✅ RESET OPTIONS: auto or manual reset with test button
✅ ADDITIONAL FEATURES: temperature compensation and trip indication
✅ PACKAGE: 1 x Thermal Overload Relay

💡 What is a thermal overload relay used for in motor protection? A handy device to guard motors from overheating in electrical systems. - Protects motor windings from overheating and overcurrent in industrial drives - Provides phase break protection to prevent motor damage in 690V circuits - Allows auto or manual reset with a dedicated test and stop control - Supports 50-60 Hz operation and temperature compensation for accuracy
